Extended version, featuring
complete set of PCR protocols and
multi-step isothermal functions

Palm PCR™ G2-12 is the extended version of the Palm PCR™series. Further to the full capacity of performing ultra-fast PCR reactions, multi-step isothermal functions are provided.
G2-12 system represents a complete solution for performing both PCR reactions and related
biochemical processes such as reverse transcription, nucleic acid preparation and cell lysis, in
a single instrument.

Key Features of G2-12 System
• Battery-powered, stand-alone device:
More than 4 hours of operation on a single charge
• Ultra-fast amplification and wide dynamic range:
18-39 min/30 cycles for up to 2 kbp amplicon
• Extreme high efficiency:
Single copy amplification sensitivity
• Multi-step isothermal functions:
For performing reverse transcription, nucleic acid
preparation, cell lysis, etc.

The Palm PCR G2-12 system consists of:
Palm PCR G2-12 Portable PCR Device,
• Model WB-1012A Wedge Base,
• Model LP-1920A Li Polymer Battery, and
• Model AD-1540A (or KPL-060H) AC/DC Adapter.

Palm PCR G2-12 System
Size (w x d x h) 71 mm x 121 mm x 47 mm
Weight 220 g (350 g including battery)
Display 1.3 inch color TFT LCD
Input power DC 11.1-15 V, 4 A
Power consumption ≤ 5 W (continuous operation) and
≤ 6.5 W (single operation) at 25°C
PCR performance PCR time 18 to 39 min/30 cycles
Dynamic range: Up to 2 kbp
Temperature Well-to-well uniformity ≤ 0.1°C
Stability ≤ 0.1°C
Accuracy ≤ 0.2°C
Number of wells 12
Sample volume 20 μL
Wedge base
size: 79 mm x 131 mm
weight: 70 g
Tilt angle: 10˚
Li+ Polymer Battery
Model LP-1920A
Size: 44.8 mm x 61.8 mm x 28.5 mm
Weight: 130 g
Outpup (nominal): DC 11.1v, 1,920mAh
Charging time: about 1.5 hours
AC/DC Adapter
Model AD-1540A
(or Model KPL-060H)
Size: 46 mm x 106 mm x 30 mm
(or 52 mm x 116 mm x 31 mm)
Weight: 175 g (or 245 g)
Input: AC 100-240 V, 50-60 Hz,
          1.5 A (or 1.7 A)
Outpup: DC 15 V, 4 A
Available in a white color only:
• RedPart No. G1012-R
• BluePart No. G1012-B
• YellowPart No. G1012-Y
